Nickel 200 Tubing, Alloy 200 Tube supplier
Nickel 200 Tube is made of a 99% nickel alloy that is known as commercially pure nickel. The material has 148MPa minimum yield strength and 462MPa minimum tensile strength but the corrosion resistance of the material is very high. Metallon Pipings FZ LLC is a leading supplier of the Nickel 200 Seamless Tube and other types of tubular products in various scales and dimensions. The material has carbon, manganese, silicon, sulfur, copper, iron and 99% nickel in the composition. As one of the leading Nickel 200 Tube Suppliers we supply the tubes in various lengths, schedules and wall thicknesses.
The material is suitable for high temperature services due to the high melting point of 1446 degrees Celsius. The Nickel 200 Tubing also has high density of 8.9grams per cubic centimeter. The tubes come in 6mm to 50.8mm outer diameters and 0.7mm to 3mm wall thicknesses with varying lengths such as single random, double random and cut to length sizes. There are square, round, rectangular and hydraulic tube types. The Alloy 200 Tube can be welded, seamless, ERW or LSAW types. Depending on the application requirements, the pipes and tubes can have different types of ends such as plain ends, threaded ends and beveled ends. The Ni200 Tube is used in severe corrosive environments such as sea water, marine, chemical, acidic and in aerospace applications. please feel free to contact us for more information on the ASTM B161 UNS N02200 tubes and their prices
Buy BS 3072 B163 UNS N02200, NA11 DIN 17740 Nickel 200 Seamless Tube, Alloy 200 hot finished seamless tubing, Nickel 200 Tubing, Ni200 Tube at best Price in UAE
Nickel Alloy 200 Tube Specification Format
| ASTM B161 Alloy 200 Tubing Standards | ASTM B161/ ASME SB161, ASME SB-161, ASME SB-163, ASME SB-730, ASME SB-751 |
|---|---|
| ASME SB-163 Alloy 200 Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| ASME SB-730 Alloy 200 Welded Tube Size | 6.35 mm OD To 152 mm OD |
| ASME SB-751 Nickel 200 Tubing Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Werkstoff 2.4066 Annealed Tubing wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| ASME SB 163 n02200 Hot Finished tubing Length | Single Random, Double Random, Standard & Cut length Tube |
| Astm B161 Uns N02200 Cold-drawn Tube Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Form | ‘U’ bent, Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Etc |
| Types of Nickel NW 2200 Tubing | Seamless, ERW, EFW, Welded, Fabricated Tube / Tubing |
| Ni 200 tubing End | Plain End, Beveled End, Treaded Tube |
| Marking | All ASTM B161 Nickel 200 Tubing are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application & uses of ASME SB 163 n02200 Hot Finished tubing | Oil Tube, Gas Tube, Fluid Tube, Boiler Tube, Heat exchanger Tube, |
| Specialize in | ASTM B161 Nickel 200 Capillary Tube & Other Odd Size Nickel NCF 200 Heat Exchanger & Condenser Tube |
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| We can also cut, thread, and groove Nickel NCF 200 Tube to meet your specifications. Nickel 200 Tube Dimension ANSI/ ASME B36.10, B36.19, B2.1 | |
Latest Alloy 200 Tubing price
| Price Of Nickel 200 Tube Manufacturer In India | ASTM B161 Nickel 200 Tube Price In India (INR) | Nickel 200 Tube Price In UK Pound Sterling | UNS N02200 Tube Price In UAE Dirham |
|---|---|---|---|
| Nickel Alloy 200 Grade Tube Size: 1.00×0.083 Thk X 1.5 Meter Length | INR 9,035 | 96.40 UK Pound Sterling | 465.33 UAE Dirham |
| Nickel Alloy 200 Seamless Tubing2 Od | INR 27,432 | 292.70 UK Pound Sterling | 1412.85 UAE Dirham |
Bulk Stock of Nickel 200 coiled tubing, Nickel 200 Polish Tube in UAE, Get fast delivery of 200 Nickel Welded Tubes
Various Types Of Alloy 200 Tube
BS 3073 Nickel 200 Seamless Tube Sizes And Schedules
| Types of Nickel 200 Tube | Out diameter (OD) | Wall thickness | Length |
|---|---|---|---|
| NB Sizes (in stock) | 1/8” ~ 8” | SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160 | Upto 6 Meters |
| Nickel 200 Seamless Tube (Custom Sizes) | 5.0mm ~ 203.2mm | As per requirement | Upto 6 Meters |
| Nickel 200 Welded Tube (in Stock + Custom Sizes) | 5.0mm ~ 1219.2mm | 1.0 ~ 15.0 mm | Upto 6 Meters |
Alloy 200 Tubing Wall Thickness
| Wall Thickness | Nickel 200 Tube Sizes ( O.D.) |
|---|---|
| .010 | 1/16″ , 1/8″ , 3/16″ |
| .020 | 1/16″ , 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ |
| .012 | 1/8″ |
| .016 | 1/8″ , 3/16″ |
| .028 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 3/4″ , 1″ , 1 1/2″ , 2″ |
| .035 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 7/16″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .049 | 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/8″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .065 | 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 3/4″ , 2″ , 2 1/2″ , 3″ |
| .083 | 1/4″ , 3/8″ , 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 7/8″ , 2″ , 2 1/2″ ,3″ |
| .095 | 1/2″ , 5/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .109 | 1/2″ , 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .120 | 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 2 1/4″ , 2 1/2″ , 3″ |
| .125 | 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 3″ , 3 1/4″ |
| .134 | 1″ |
| .250 | 3″ |
| .375 | 3 1/2″ |
Check Ni200 Tube, Nickel 200 Instrumentation tubes, Nickel Alloy Werkstoff Nr. 2.4060 Welded Tubes Dimension Chart, View Price list of DIN 17751 Alloy 200 boiler tube.
Nickel 200 Tubing Pressure Rating
| Tube O.D. (in.) | Wall Thickness of Tube (inches) | |||||||
|---|---|---|---|---|---|---|---|---|
| .028 | .035 | .049 | .065 | .083 | .095 | .109 | .120 | |
| Working Pressure (psig) | ||||||||
| 1/8 | 7900 | 10100 | ||||||
| 1/4 | 3700 | 4800 | 7000 | 9500 | ||||
| 5/16 | 3700 | 5400 | 7300 | |||||
| 3/8 | 3100 | 4400 | 6100 | |||||
| 1/2 | 2300 | 3200 | 4400 | |||||
| 3/4 | 2200 | 3000 | 4000 | 4600 | ||||
| 1 | 2200 | 2900 | 3400 | 3900 | 4300 | |||
Physical Properties of BS 3076 Ni200 Tube
| Grade | ASTM B163 Nickel 200 | |
|---|---|---|
| Density | 8.9 g/cm3 | |
| Melting Point | 1446 °C (2635 °F) | |
Alloy 200 nickel tubing Test & Certificate
- Material certificate type EN 10204 Type 3.1
- Micro and MacroTest
- Positive Material Identification – PMI Testing
- Hardness Test
- Chemical Analysis – Spectro Analysis
- Intergranular Corrosion (IGC) Test
- Flaring Test
- Flattening Test
- Pitting Resistance Test
- Mechanical Testing Such as Tensile of Area
Equivalent Material Nickel 200 Polish Tube
| Grade | ASTM B163 Nickel 200 | |
| UNS No | N02200 | |
| Old British | BS | NA 11 |
| En | Ni 99.2 | |
| Euronorm | No | 2.4066 |
| Name | – | |
| AFNOR | N-100M | |
| Japanese JIS | NW 2200 | |
| GOST | НП-2 | |
Ready Stock of ASTM B622 Nickel 200 heat exchanger tube, DIN 17750 Nickel UNS N02200 Tubing, Nickel Werkstoff Nr. 2.4060 Tubing, Buy Nickel NW 2200 cold drawn seamless tube at low price
200 Nickel Welded Tubes Chemical Properties
| Grade | ASTM B163 Nickel 200 | |
|---|---|---|
| min | max | |
| C | – | 0.15 |
| Mn | – | 0.35 |
| Si | – | 0.1 |
| P | – | – |
| S | – | 0.01 |
| Mg | – | – |
| Ti | – | – |
| Ni | 99.0 | – |
| Cu | – | 0.25 |
| Fe | – | 0.4 |
Nickel 200 Seamless Tube Mechanical Behaviour
| Grade | ASTM B163 Nickel 200 | |
|---|---|---|
| Tensile Strength (MPa) min | Psi – 67000 , MPa – 462 | |
| Yield Strength 0.2% Proof (MPa) min | Psi – 21500 , MPa – 148 | |
| Elongation (% in 50mm) min | 45% | |
Available Inventory Of ASME SB 163 N02200 Hot Finished tubing
| Alloy | Product form | Dimension |
|---|---|---|
| NICKEL 200 (99.0 Ni min) | Tube; cold drawn, annealed, seamless | 16.0 x 1.5 mm |
| NICKEL 200 (99.0 Ni min) | Tube; cold drawn, annealed | 33.4 x 3.38 mm (1″nb sch40s) |
| NICKEL 200 (99.0 Ni min) | Tube; cold drawn, annealed | 48.26 x 2.77 mm (1½”nb sch10s) |
| NICKEL 200 (99.0 Ni min) | Tube; cold drawn, annealed | 60.33 x 2.77 mm (2″nb Sch10s) |
| NICKEL 200(99.0 Ni min) | Tube; cold drawn, annealed | 60.33 x 3.91 mm (2″nb sch40s) |
| NICKEL 200 (99.0 Ni min) | Tube; cold drawn, annealed | 88.9 x 3.05 mm (3″nb Sch10s) |
| NICKEL 200 (99.0 Ni min) | Tube; cold drawn, annealed | 114.3 x 3.05 mm (4″nb Sch10s) |
