EN 10210-1 S355J2H Pipe, S355j2h CHS Tube exporter
S355J2H EN 10210 Tube is made up of a 0.22% carbon included low carbon steel that is ductile, hard, strong and corrosion resistant. The material has silicon, manganese, phosphorus and sulfur in the composition. The combination of elements in the En 10210 S355j2h Material provides it with 355MPa minimum yield strength and 630MPa minimum tensile strength. The material comes in different sizes, shapes and types.
The diameters of the en 10210-1 seamless pipe ranges from 4mm to 219mm and the wall thickness ranges from 0.5mm to 20mm. The welded and ERW pipes have higher diameters up to 1219.2mm. The S355j2h Seamless Tube has lower diameters ranging from 3.35mm to 101.6mm. There are different schedules to the tubes ranging from sch5 through XXS. The material comes in single random, double random and cut to length sizes. There are also different finishes to the material such as polished, annealed and pickled and bright annealed. The form of the s355j2h EN 10219 pipes range from round hydraulic and straight to boiler, rectangular and square forms. The different forms are used in different application circumstances. The En 10210 S355j2h Steel Pipe can have plain ends and threaded ends as well. The applications include petroleum, petrochemical, oil and gas industries where the fluids and gases are transmitted from one location to another via pipelines. Please feel free to order your Bs En 10210 S355j2h products with us.
Buy EN 10210 S355J2H Structural Hollow Sections, EN 10210-1 S355J2H Steel CHS Tube at lowest price in UAE
Material Specification of EN 10210 S355J2H Seamless Pipe
| Size | Round Pipes – OD 13.7-1214mm Square Pipes – 10 X 10 mm – 800 X 800 mm Rectangular Pipes – 10mm x 20mm – 400 x 800mm |
| Wall Thickness | 1.0mm – 40mm |
| Length | 6 Meter, 12 Meter & Custom Size |
| Type | Square, Round, Rectangular Seamless, Welded, Fabricated, ERW |
| Surface Finish | Shot blasting, Black Phosphating, Black, Oiled, Paint, Hairline, Mirror, Galvanized, Anti Corrosive |
| Material grades | ASTM A500 – Gr.A, Gr.B, Gr.C, Gr.D SS330, SS400, STK490, C250, C350, C450 EN 10210/EN 10219 – S185, S235JR, S235J0, S355JR, S355J0, S355J2 20#, 45#, 16Mn, 304, 304L, 316, 316L |
| End Type | Plain, Bevel, Screwed, Threaded |
Carbon Steel S355J2H EN 10210 Pipes Heat Treatment
| Hot Forming | Heat Treatment | |||
| Temperature°C | Cooling Type | Normalizing 1″ | Stress relieving anneal 2″ | Cooling Type |
| 700-750 | Air | 850-950°C | 580-630°C | Air |
Manufacturer of En 10210 S355j2h Steel Pipe, Carbon Steel S355j2h En 10210 Pipe, Check EN 10210-1 Steel Pipes Price
Most Commonly Used EN 10210-1 Grade S355J2H Carbon Steel Pipes Types
EN 10210-1 Grade S355J2H Carbon Steel Seamless Pipes, S355j2h EN 10210 Tube Manufacturer, View En 10210 S355j2h Material Specification
S355j2h EN 10210 Tube Sizes In Mm
| 1/8″ IPS(.405″ O.D.) | 3 1/2″ IPS( 4.000″ O.D.) |
|---|---|
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4″ IPS(.540″ O.D.) | 4″ IPS(4.500″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8″ IPS(.675″ O.D.) | 5″ IPS( 5.563″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2″ IPS(.840″ O.D.) | 6″ IPS(6.625″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4″ IPS(1.050″ O.D.) | 8 ” IPS(8.625″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1″ IPS:(1.315′ O.D.) | 10″ IPS(10.750″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4″ IPS(1.660″ O.D.) | 12″ IPS(12.750″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2″ IPS(1.900″ O.D.) | 14″ IPS(14.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2″ IPS(2.375″ O.D.) | 16″ IPS(16.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2″ IPS(2.875″ O.D.) | 18″ IPS (18.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
| 3″ IPS( 3.500″ O.D.) | |
| SCH 5, 10, 40, 80, 160, XXH |
| Wall | Sizes ( O.D.) |
|---|---|
| .010 | 1/16″ , 1/8″ , 3/16″ |
| .020 | 1/16″ , 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ |
| .012 | 1/8″ |
| .016 | 1/8″ , 3/16″ |
| .028 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 3/4″ , 1″ , 1 1/2″ , 2″ |
| .035 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 7/16″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .049 | 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/8″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .065 | 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 3/4″ , 2″ , 2 1/2″ , 3″ |
| .083 | 1/4″ , 3/8″ , 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 7/8″ , 2″ , 2 1/2″ ,3″ |
| .095 | 1/2″ , 5/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .109 | 1/2″ , 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .120 | 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 2 1/4″ , 2 1/2″ , 3″ |
| .125 | 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 3″ , 3 1/4″ |
| .134 | 1″ |
| .250 | 3″ |
| .375 | 3 1/2″ |
EN 10210-1 Grade S355J2H Pipes supplier, Buy En 10210 S355j2h Hot Rolled Square Pipes, En 10210 Square Tube at the best price, Check En 10210 S355j2h Hot Rolling Seamless Pipe Size chart
S355j2h CHS Tube Chemical Compatibility Chart
| Steel Grade | Chemical Composition Limits (%) | |||||
| C Max. | Si Max. | Mn Max. | P Max. | S Max. | N Max. | |
| S235JRH | 0.17 | – | 1.40 | 0.040 | 0.040 | 0.009 |
| S275J0H | 0.20 | – | 1.50 | 0.035 | 0.035 | 0.009 |
| S275J2H | 0.20 | – | 1.50 | 0.030 | 0.030 | – |
| S355J0H | 0.22 | 0.55 | 1.60 | 0.035 | 0.035 | 0.009 |
| S355J2H | 0.22 | 0.55 | 1.60 | 0.030 | 0.030 | – |
| S355K2H | 0.22 | 0.55 | 1.60 | 0.030 | 0.030 | – |
EN 10210-1 Steel Pipes Mechanical Properties Analysis
| Steel Grade | Mechanical Properties | Impact Energy (KV J) | ||||
| Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation (%) | Test Temperature At Test Temperature of ℃ | |||
| -20 | 0 | 20 | ||||
| S235JRH | 235 | 360-510 | 26 | – | – | 27 |
| S275J0H | 275 | 410-560 | 23 | – | 27 | – |
| S275J2H | 275 | 410-560 | 23 | 27 | – | – |
| S355J0H | 355 | 510-680 | 22 | – | 27 | – |
| S355J2H | 355 | 510-680 | 22 | 27 | – | – |
| S355K2H | 355 | 510-680 | 22 | 40 | – | – |
