SS 304L Slip On Flanges, Stainless Steel 304H RTJ Flange, Stainless Steel 304L Pipe Flanges, SS 304H Spacer, SS UNS S30403 Pipe Flanges, SS UNS S30409 Pipe Flanges, ANSI B16.5 SS 304L Orifice Flange Supplier in UAE.
Metallon Pipings FZ LLC Inc is one of the pioneer trading house and dealer of SS 304L/304H Flanges, which is a molybdenum bearing and low carbon content “l” grade austenitic stainless steel that provides improved corrosion resistance. The low carbon in Stainless Steel 304L Slip On Flanges provides resistance to sensitization during welding and other thermal processes. Stainless Steel 304H Threaded Flanges is non – magnetic in the annealed condition but may become slightly magnetic as a result of welding. Stainless Steel 304L Weld Neck Flanges have excellent corrosion resistance in a wide range of chemicals, especially in acidic chloride environments such as those encountered in pulp and paper mills.
Stainless Steel 304L Flanges, SS ASTM A182 F304L Long Weld Neck Flanges, ASTM A182 Stainless Steel 304H Flanges Supplier, SS 304L Ring Type Joint – RTJ Flanges, SS 304H Slip on Flanges, Stainless Steel 304H Weld Neck Flanges, ASTM A182 Stainless Steel 304L Blind Flanges Exporter, SS 304H Flanges Manufacturer in UAE.
Stainless Steel 304H Blind Flanges is resistant to sulphuric acid concentrations up to five percent at temperatures as high as 120 Degree f (49 Degree c) at temperatures under 100 Degree f (38 Degree c). Stainless Steel UNS S30403 Socket Weld Flanges has excellent resistance to solutions of higher concentration. Stainless Steel 304L Lap Joint Flanges are slightly improved corrosion resistance over other alloys of stainless steel in strongly oxidizing environments as a result of the addition of columbium (niobium) and tantalum. SS 304H Ring Joint Type Flanges does not perform well in chloride solutions, even in small concentrations, or in sulphuric acid. The machinability of Stainless Steel 304L Spectacle Blind Flanges is difficult as it work-hardens during machining. The conventional machining techniques used on iron alloys may be used for Stainless Steel 304H Nippo Flanges.
Standard Specification For SS 304L/304H Flanges
Specifications
ASTM A182 / ASME SA182
Size
1/2″ (15 NB) to 48″ (1200NB)
Standards
ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
SS 304L/304H Pipe Flanges Chemical Composition
Grade
C
Mn
Si
P
S
Cr
Mo
Ni
N
SS 304L
0.035 max
2 max
1.0 max
0.045 max
0.030 max
18 – 20
–
8 – 13
–
SS 304H
0.10 max
2 max
0.75 max
0.045 max
0.030 max
18 – 20
–
8 – 10.5
–
SS 304L/304H Plate Flanges Mechanical Properties
Density
Melting Point
Tensile Strength
Yield Strength (0.2%Offset)
Elongation
8.0 g/cm3
1400 °C (2550 °F)
Psi – 75000 , MPa – 515
Psi – 30000 , MPa – 205
35 %
SS 304L/304H Plate Flanges For Equivalent Grades
STANDARD
WERKSTOFF NR.
UNS
JIS
BS
GOST
AFNOR
EN
SS 304L
1.4306 / 1.4307
S30403
SUS 304L
3304S11
03Х18Н11
Z3CN18‐10
X2CrNi18-9 / X2CrNi19-11
SS 304H
1.4301
S30409
–
–
–
–
–
Stainless Steel 304L/304H Flanges Packaging
Stainless Steel 304L/304H Flanges are widely used in various industries including petrochemical, oil and gas, power generation, bulk liquid transportation, chemicals, pharmaceuticals, pulp and paper manufacturing, textiles and others. All our SS 304L/304H Flange are manufactured in accordance with international standards. Stainless Steel 304L/304H Pipe Flange are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All Stainless Steel 304L/304H Plate Flanges are marked with Grade, Lot No, Size, Degree and our trade mark. On special requests we can also, make custom marking on 304L/304H Stainless Steel Flanges
Contact us to know more.
