ANSI B16.11 Stainless Steel 304L Tube Fittings, SS 1.4948 Tube Male Elbow, Stainless Steel 304L Tube Fittings, 304L SS Connector, SS S30409 Tube Fittings, ASTM A182 304L SS Tube Fittings 45 Elbow, Stainless Steel 304h Tube Fittings Supplier in UAE.
We are engaged in offering a wide range of Stainless Steel 304L / 304H Tube Fittings, Stainless Tube Fittings, and Stainless Steel Pipe Fittings, which includes Male Connectors, Female Connectors, Stainless Steel Union and Other Stainless Steel Tube Fittings.
ASME SA 182 SS 304L Connector, Stainless Steel 304h Union, SS 304L Tube Fittings Tee, Stainless Steel 304h Tube Fittings Tee Stockist, Stainless Steel 304L High Pressure Tube Fittings, SUS 304h Tube Fittings, SS 304L Tube Fittings Reducers Exporter in UAE.
Metallon Pipings FZ LLC is one of the leading Exporter, and Supplier of Stainless Steel Tube Fittings using high quality raw materials as per customer specific requirements. Our offered range of stainless steel tube fittings is widely used in various application industries such as power plants, automobile, heavy engineering, offshore and chemical etc.
Standard Specification For SS 304L/304H Tube Fittings
Specifications
ASTM A276 ASME SA 479
Tube Size
6mm to 38mm to 1/4″ to 1 1/2″
Size
1/8” NB TO 48” NB.
Thread
NPT, BSP, BSPT, UNF, ISO, SAE etc.
Brass
ASTM B16 ASTM B 453
Pressure Rating
6000PSI for Stainless Steel, 300/1000/3000PSI for Brass
SS 304L/304H Tube Fittings for Chemical Composition
Grade
C
Mn
Si
P
S
Cr
Mo
Ni
N
SS 304L
0.035 max
2 max
1.0 max
0.045 max
0.030 max
18 – 20
–
8 – 13
–
SS 304H
0.10 max
2 max
0.75 max
0.045 max
0.03 max
18 – 20
–
8 – 10.5
–
SS 304L/304H Tube Fittings For Mechanical Properties
Grade
Density
Melting Point
Tensile Strength
Yield Strength (0.2%Offset)
Elongation
SS 304L
8.0 g/cm3
1400 °C (2550 °F)
Psi – 75000 , MPa – 515
Psi – 30000 , MPa – 205
35 %
SS 304H
8.0 g/cm3
1400 °C (2550 °F)
Psi – 75000 , MPa – 515
Psi – 30000 , MPa – 205
40 %
SS 304L/304H Tube Fittings For Equivalent Grades
STANDARD
WERKSTOFF NR.
UNS
JIS
BS
GOST
AFNOR
EN
SS 304L
1.4306 / 1.4307
S30403
SUS 304L
3304S11
03Х18Н11
Z3CN18‐10
X2CrNi18-9 / X2CrNi19-11
SS 304H
1.4948
S30409
SUS 304H
–
–
–
–
Stainless Steel 304L/304H Tube Fittings Packaging
Stainless Steel 304L/304H Tube Fittings are widely used in various industries including petrochemical, oil and gas, power generation, bulk liquid transportation, chemicals, pharmaceuticals, pulp and paper manufacturing, textiles and others. All our SS 304L Tube Fittings are manufactured in accordance with international standards. Stainless Steel 304H Tube Fittings are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All Stainless Steel 304L Tube Fittings are marked with Grade, Lot No, Size, Degree and our trade mark. On special requests we can also, make custom marking on 304L/304H Stainless Steel Tube Fittings.
Contact us to know more.
Looking for more details on our products? Fill up the form and our team of experts will contact you shortly
