Stainless Steel 316Ti Nippolet Flanges, ANSI B16.5 SS 316 Ring Type Joint Flanges, Stainless Steel 316 Pipe Flanges, SS 316Ti Weld Neck Flange, Stainless Steel 316Ti RTJ Flange, SS 316 Lap Joint Flange Supplier in UAE, 316 Stainless Steel Flanges, 316Ti Stainless Steel Flange, Stainless Steel 316Ti Flanges.
Metallon Pipings FZ LLC is one of the well-established producers for SS 316 / 316Ti Flanges, which performs well in boiling 20% phosphoric acid. Our Stainless Steel 316 Slip On Flanges can also be used in the food and pharmaceutical process industries where it is utilized to handle hot organic and fatty acids in an effort to minimize product contamination. These Stainless Steel 316Ti Threaded Flanges performs well in fresh water service even with high levels of chlorides. In most instances, the corrosion resistance of our Stainless Steel 316 Weld Neck Flanges will be roughly equal in most corrosive environments. However, in environments that are sufficiently corrosive to cause intergranular corrosion of welds and heat – affected zones, these Stainless Steel UNS S31600 / S31635 Blind Flanges should be used for the reason that of its low carbon content.
ANSI B16.5 SS 316 Orifice Flange, SS 316Ti Spacer, SS UNS S31600 Pipe Flanges, SS 316Ti Slip On Flanges, SS GOST 08Ch17N13M2T Screwed Flanges Stockist, SS 316Ti Spectacle Blind Flanges, UNS S31600 SS WNRF Flanges Exporter, SS 316Ti Blind Flanges Dealer, SS 316 Flanges Exporters, SS 316Ti Chemical Composition.
Our Stainless Steel 316 Socket Weld Flanges can be easily welded and processed by standard shop fabrication practices. Forming working temperatures of 1700 Degree F – 2200 Degree F (927 Degree – 1204 Degree C) are recommended in these Stainless Steel 316L Lap Joint Flanges for most hot working processes. Our Stainless Steel 316 Ring Joint Type Flanges is quite ductile and forms easily, which is subject to work hardening during deformation and is subject to chip breaking. Cold working operations will increase the strength and hardness of these Stainless Steel 316L Spectacle Blind Flanges and might leave it slightly magnetic.
Standard Specification For SS 316 / 316Ti Flanges
Specifications
ASTM A182 / ASME SA182
Size
1/2″ (15 NB) to 48″ (1200NB)
Standards
ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
SS 316 / 316Ti Pipe Flanges Chemical Composition
Grade
C
Mn
Si
P
S
Cr
Mo
Ni
N
SS 316
0.08 max
2 max
1.0 max
0.045 max
0.030 max
16.00 – 18.00
2.00 – 3.00
11.00 – 14.00
67.845 min
SS 316Ti
0.08 max
2 max
0.75 max
0.045 max
0.030 max
16.00 – 18.00
2.00 – 3.00
10.00 – 14.00
68.395 min
SS 316 / 316Ti Plate Flanges Mechanical Properties
Grade
Density
Melting Point
Tensile Strength
Yield Strength (0.2%Offset)
Elongation
SS 316
8.0 g/cm3
1400 °C (2550 °F)
Psi – 75000 , MPa – 515
Psi – 30000 , MPa – 205
35%
SS 316Ti
8.0 g/cm3
1399 °C (2550 °F)
Psi – 75000 , MPa – 515
Psi – 30000 , MPa – 205
35%
SS 316 / 316Ti Plate Flanges Equivalent Grades
STANDARD
WERKSTOFF NR.
UNS
JIS
BS
GOST
AFNOR
EN
SS 316
1.4401 / 1.4436
S31600
SUS 316
316S31 / 316S33
–
Z7CND17‐11‐02
X5CrNiMo17-12-2 / X3CrNiMo17-13-3
SS 316Ti
1.4571
S31635
SUS 316Ti
320S31
08Ch17N13M2T
Z6CNDT17‐123
X6CrNiMoTi17-12-2
Stainless Steel 316 / 316Ti Flanges Packaging
Stainless Steel 316 / 316Ti Flanges are widely used in various industries including petrochemical, oil and gas, power generation, bulk liquid transportation, chemicals, pharmaceuticals, pulp and paper manufacturing, textiles and others. All our SS 304 Flange are manufactured in accordance with international standards. Stainless Steel 316 / 316Ti Pipe Flange are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All Stainless Steel 316 / 316Ti Plate Flanges are marked with Grade, Lot No, Size, Degree and our trade mark. On special requests we can also, make custom marking on 316 / 316Ti Stainless Steel Flanges.
Contact us to know more.
