Stainless Steel 316L Nippolet Flanges, ANSI B16.5 SS F316L Ring Type Joint Flanges, Stainless Steel 316L Pipe Flanges, SS 316L Weld Neck Flange, Stainless Steel 316L RTJ Flange, SS 316L Lap Joint Flange Supplier in UAE, 316L Stainless Steel Flanges, 316L Stainless Steel Flange, Stainless Steel 316L Flanges.
Metallon Pipings FZ LLC is one of the well-established producers for 316L Flanges, which performs well in boiling 20% phosphoric acid. Our Stainless Steel 316L Slip On Flanges can also be used in the food and pharmaceutical process industries where it is utilized to handle hot organic and fatty acids in an effort to minimize product contamination. These Stainless Steel 316L Threaded Flanges performs well in fresh water service even with high levels of chlorides. In most instances, the corrosion resistance of our Stainless Steel 316L Weld Neck Flanges will be roughly equal in most corrosive environments. However, in environments that are sufficiently corrosive to cause intergranular corrosion of welds and heat – affected zones, these Stainless Steel S31603 Blind Flanges should be used for the reason that of its low carbon content.
SS DIN 1.4436 Socket Weld Flanges, ASTM A182 SS F316L Threaded Flanges, SS 316L Nippo Flanges, ASME SA182 Stainless Steel 316L Industrial Flanges, Stainless Steel 316L Spade Flanges, SS 316L Forged Flanges, 150# ANSI SS 316L Flanges Stockholder, Manufacturer in UAE.
Our Stainless Steel 316L Socket Weld Flanges can be easily welded and processed by standard shop fabrication practices. Forming working temperatures of 1700 Degree F – 2200 Degree F (927 Degree – 1204 Degree C) are recommended in these Stainless Steel 316L Lap Joint Flanges for most hot working processes. Our Stainless Steel 316L Ring Joint Type Flanges is quite ductile and forms easily, which is subject to work hardening during deformation and is subject to chip breaking. Cold working operations will increase the strength and hardness of these Stainless Steel 316L Spectacle Blind Flanges and might leave it slightly magnetic.
Standard Specification For SS 316L Flanges
Specifications
ASTM A182 / ASME SA182
Size
1/2″ (15 NB) to 48″ (1200NB)
Standards
ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
SS 316L Pipe Flanges Chemical Composition
Grade
C
Mn
Si
P
S
Cr
Mo
Ni
N
SS 316L
0.035 max
2 max
1.00 max
0.045 max
0.030 max
16.00 – 18.00
2.00 – 3.00
10.00 – 14.00
68.89 min
SS 316L Plate Flanges Mechanical Properties
Density
Melting Point
Tensile Strength
Yield Strength (0.2%Offset)
Elongation
8.0 g/cm3
1399 °C (2550 °F)
Psi – 75000 , MPa – 515
Psi – 30000 , MPa – 205
35%
SS 316L Plate Flanges Equivalent Grades
STANDARD
WERKSTOFF NR.
UNS
JIS
BS
GOST
AFNOR
EN
SS 316L
1.4404 / 1.4435
S31603
SUS 316L
316S11 / 316S13
03Ch17N14M3 / 03Ch17N14M2
Z3CND17‐11‐02 / Z3CND18‐14‐03
X2CrNiMo17-12-2 / X2CrNiMo18-14-3
Stainless Steel 316L Flanges Packaging
Stainless Steel 316L Flanges are widely used in various industries including petrochemical, oil and gas, power generation, bulk liquid transportation, chemicals, pharmaceuticals, pulp and paper manufacturing, textiles and others. All our SS 316L Flange are manufactured in accordance with international standards. Stainless Steel 316L Pipe Flange are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All Stainless Steel 316L Plate Flanges are marked with Grade, Lot No, Size, Degree and our trade mark. On special requests we can also, make custom marking on 316L Stainless Steel Flanges.
