SS UNS S32100 Pipe Flanges, ANSI B16.5 SS 321 Orifice Flange, Stainless Steel 321 Pipe Flanges, 150# ANSI SS 321 Flanges, SS 321 Spacer, Stainless Steel 321 Slip On Flanges Supplier in UAE.
Metallon Pipings FZ LLC leading stockiest, exporter, and supplier of SS 321 / 321H Flanges, which has oxidation resistant to 1600 ° F. Stainless Steel 321 Flanges is developed to provide an 18-8 type alloy with improved inter-granular-corrosion resistance. Stainless Steel 321H Flanges is not subject to weld decay (inter-granular corrosion) when exposed to mildly corrosive environments. Stainless Steel 321 Slip On Raised Flanges is a titanium stabilized chromium-nickel austenitic stainless steel with good strength and excellent corrosion resistance, as supplied in the annealed condition. Stainless Steel 321 Blind Raised Flanges is an excellent choice for various applications ranging from oil refinery equipment to automotive exhaust systems.
SS 321H Spectacle Blind Flanges, SS 321H Spade Flange, SS GOST 08Х18Н10 Screwed Flanges Stockist, ANSI B16.5 SS F321 Ring Type Joint Flanges, SS 321 Nippo Flanges, Stainless Steel F321 Industrial Flanges Stockholder, ASME SA182 SS 321H Lap Joint Flange, SS Grade F321 Forged Flanges Manufacturer.
Stainless Steel 321 Weld Neck Flanges can be readily formed and drawn, however, higher pressures are required and more spring-back is encountered than for carbon steel and ferrite stainless steels. Stress Relief – Heat this Stainless Steel 321 Socket Weld Flanges up to 700 ° C for 1 to 2 hours and air cool. Stainless Steel 321 Threaded Flanges contains 18 % chromium, 8 % nickel and a substantial addition of titanium. Stainless Steel 321 Spectacle Blind Flanges has comparable corrosion resistance and machinability to Stainless Steel 304. Stainless Steel 321 Lap Joint Flanges is not suitable for work at temperatures below 1700 ° F (927 ° C). Titanium is added to the composition of Stainless Steel 321H Ring joint Type Flanges to suppress grain boundary chromium carbide precipitation and reduce susceptibility to inter-granular corrosion.
Standard Specification For SS 321 / 321H Flanges
Specifications
ASTM A182 / ASME SA182
Size
1/2″ (15 NB) to 48″ (1200NB)
Standards
ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
SS 321 / 321H Pipe Flanges Chemical Composition
Grade
C
Mn
Si
P
S
Cr
Mo
Ni
N
SS 321
0.08 max
2.0 max
1.0 max
0.045
0.045 max
0.030 max
17.00 – 19.00
0.10 max
9.00 – 12.00
SS 321H
0.04 – 0.10
2.0 max
1.0 max
0.045
0.045 max
0.030 max
17.00 – 19.00
0.10 max
9.00 – 12.00
SS 321 / 321H Plate Flanges Mechanical Properties
Density
Melting Point
Tensile Strength
Yield Strength (0.2%Offset)
Elongation
8.0 g/cm3
1457 °C (2650 °F)
Psi – 75000 , MPa – 515
Psi – 30000 , MPa – 205
35%
Equivalent Grades for SS 321 / 321H Plate Flanges
STANDARD
WERKSTOFF NR.
UNS
JIS
EN
SS 321
1.4541
S32100
SUS 321
X6CrNiTi18-10
SS 321H
1.4878
S32109
SUS 321H
X12CrNiTi18-9
Stainless Steel 321 / 321H Flanges Packaging
Stainless Steel 321 Flanges are widely used in various industries including petrochemical, oil and gas, power generation, bulk liquid transportation, chemicals, pharmaceuticals, pulp and paper manufacturing, textiles and others. All our SS 321 Flange are manufactured in accordance with international standards. Stainless Steel 321H Pipe Flange are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All Stainless Steel 321 Plate Flanges are marked with Grade, Lot No, Size, Degree and our trade mark. On special requests we can also, make custom marking on 321 Stainless Steel Flanges.
Contact us to know more.
