ANSI B16.5 Super Duplex Stainless Steel S32750 Orifice Flange, Super Duplex F53 Spacer,Super Duplex Steel S32750 Pipe Flanges, Super Duplex Steel S32750 Flanges, Super Duplex UNS S32760 Pipe Flanges, Super Duplex F55 Spectacle Blind Flanges, Super Duplex F55 Spade Flanges, Super Duplex 2507 Slip On Flanges Supplier in UAE, UNS S32750 Pipe Suppliers, Super Duplex Flanges.
Metallon Pipings FZ LLC offers a wide range of Super Duplex Steel S32750 / S32760 Flanges, where the professionals working with us make use of high quality equipment and latest methodologies to manufacture the offered range of products. The duplex microstructure gives these Super Duplex Steel S32750 Slip On Flanges a low coefficient of thermal expansion and higher heat conductivity than austenitic steels and is suitable for working temperatures up to 300 Degree C. Our Super Duplex Steel S32760 Threaded Flanges is often used in Marine Industry and Shipbuilding: such as in Propellers and Shafts, Rudders, Shaft Seals, Pumps, Bolts and Fasteners, Valves, Instrumentation, Oil and Chemical Tankers.
ASME SA182 Super Duplex S32950 Lap Joint Flange, ANSI B16.5 Super Duplex S32750 Ring Type Joint Flanges, Super Duplex Steel F53 Industrial Flanges Stockholder, Super Duplex Steel S32760 Screwed Flanges Stockist, Super Duplex F55 Nippolet Flanges, S32750 Super Duplex Steel Forged Flanges Manufacturer.
Meanwhile, these Super Duplex Steel S32750 Weld Neck Flanges are also being offered in different sizes and shapes to our customers. Because our Super Duplex Steel S32760 Blind Flanges is substantially better than either SS 316L or SS 904L in this situation, it is a good candidate for wet process phosphoric acid applications. Ganpat Industrial Corporation is one of the pioneer exporter and supplier of our Super Duplex Steel S32750 Socket Weld Flanges, which are susceptible to loss exposures leading to precipitation of phases other than chromium carbide. The very low carbon content of these Super Duplex Steel S32760 Lap Joint Flanges in combination by means of its generally very good corrosion resistance make the steel essentially immune to inter – granular corrosion caused by chromium carbide precipitation.
Standard Specification For Super Duplex S32750/ S32760 Flanges
Specifications
ASTM A182 / ASME SA182
Size
1/8″ NB TO 24″ NB
Standards
ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Grades
S32750 / S32760 / S32950
Super Duplex S32750/ S32760 Flanges Chemical Composition
Grade
C
Mn
Si
P
S
Cr
Mo
Ni
N
Fe
S32750
0.030 max
1.20 max
0.80 max
0.035 max
0.020 max
24.00 – 26.00
3.00 – 5.00
6.00 – 8.00
0.24 – 0.32
58.095 min
S32760
0.05 max
1.00 max
1.00 max
0.030 max
0.010 max
24.00 – 26.00
3.00 – 4.00
6.00 – 8.00
0.20 – 0.30
57.61 min
Super Duplex S32750 / S32760 Flanges Mechanical Properties
Grades
Density (g/cm 3)
Density (lb/in 3)
Melting Point (°C)
Melting Point (°F)
S32750 / S32760
7.8
0.281
1350
2460
Equivalent Grades for Super Duplex S32750 / S32760 Flanges
STANDARD
WERKSTOFF NR.
UNS
Super Duplex 2507
1.4410
S32750
Super Duplex 2507
1.4501
S32760
Super Duplex S32750 / S32760 Flanges Packaging
Super Duplex Steel S32750 Flanges are widely used in various industries including petrochemical, oil and gas, power generation, bulk liquid transportation, chemicals, pharmaceuticals, pulp and paper manufacturing, textiles and others. All our SS S32750 Flange are manufactured in accordance with international standards. Super Duplex Steel S32750 Pipe Flange are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All Super Duplex Steel S32750 Plate Flanges are marked with Grade, Lot No, Size, Degree and our trade mark. On special requests we can also, make custom marking on S32750 Super Duplex Steel Flanges.
Contact us to know more.
Looking for more details on our products? Fill up the form and our team of experts will contact you shortly
